LGMG SR1018D - 5.2 PCU

Elevating Work Platform Operation Manual
60
5.2 PCU
5.2.1 PCU
No.
Name
Operation function description
1
Functional enabling button of outrigger with indicator
Press this button to activate the
ascending/descending functions of single
outrigger.
2
Automatic leveling button of outrigger
Press this button to activate the
automatic leveling function.
3
Startup button of engine
Press this button to start up the engine.
4
Idling selection button of engine with indicator
Press this button to select the idling
setting of engine. The indicator is on,
indicating that the high idling has been
selected. The indicator is off, indicating
that the intermediate and low idling has
been selected.
5
Glow plug button
Press this button to activate the glow
plug.
6
Gasoline/LPG model: LPG operating button with
indicator
Press this button to select LPG.
7
Horn button
Press this button, and the horn will sound.
Release this button, and the horn will stop
sounding.
