LGZ USB - Technical Specifications Table

[LGZ USB USER MANUAL]
LGZ USB
LGZ Broadcasting Tech | Copyright 2013 | Technical Specifications table
5
Technical Specifications table
LGZ USB
Comments
Video Inputs
(option for Decklink
Studio card)
1 x HD/SD-SDI
Additional input types
available with the Decklink
Studio option
Video format
SD-SDI PAL 576i
HD-SDI 720p50
HD-SDI 1080i50
(1080i5994, 720p60 and
480i are also available since
software 1.8)
Audio Inputs
2 channels (embedded)
(audio pair can be chosen)
AES stereo available with
Decklink Studio option
ON/OFF Switch
1 x on front
Press once to turn on or off
Interface
1 x LCD screen with buttons
All features can also be
controlled via the Web
Interface
Dimensions
1U 19” rackmountable
35 cm deep. Can be
mounted without support rail
Weight
4 kg
Power supply
300W 100-240V
50-60Hz
Temperature (in use)
10 ~ 45°C
Temperature (storage)
- 30 ~ 60°C
Air humidity (in use)
20 % ~ 80 %
High temperature differences
may result in condensation.
Shock resistance (storage)
5G
Shock resistance (lagring)
70G
Heat build-up
1109 BTU/hour
Maximum theoretical value
Altitude (in use)
-20 ~ 3000m
Altitude (storage)
-20 ~11000m
Sound level
~ 40 dB
dB SPL level at 1m distance
