22
Fig. 7 --- Tank Overall Dimensions (supply not mounted on unit)
F
F
F
F
M
M
M
F
F F
F
500 500
1300
2240
1000
791 842 607
115 1185
155765300765255
115 1185
255 765 300 765 155
1151185
562 1300 378
M
REMOVABLE
PANEL
F
PREPUNCHED ø110
(for inlet/outlet
pipes connections)
TOP VIEW
FRONT VIEW
SX LATERAL VIEW
DX LATERAL VIEW
PART . ”G”
”N”
229
L=120mm
DN80---3”
88.9mm
“N” VIEW
TANK CONNECTING
PIPE
V
V
V
VICTAUL IC COUPLING DN80---3”
PART . “G”
TANK CONNECTING
SYSTEM
BRACKETS
N. 2 brackets for supported inlet/
outlet pipes. Fixed with M6 screws
in (ø7) holes, near prepunched
connections (ø110) chosen.
To Next Page
