Liebert CBH 017 - Drawings

15
Fig. 1 --- Service areas (top view)
1000 1000
15001500
Extraordinary
maintenance area
Notes:
Minimum distance between 2 units from condensing coil side = 3 m
Do not obstruct the air exiting the fans for a minimum distance of 2.5 m
AIR
Ordinary
maintenance area
