Liebert HPSE User Manual

8
Dimensional Drawings
8--1
Liebert HPS---PD--- 272965---20.11.2009
F i g . 4 --- E v a p o r a t i n g u n i t HPSE 06 (version with freecooling)
Condensate drain
228 150
150 150 125
13,583313,5
803
251,5 300 251,5
310
155155
28.528.5 803
310
FRONT VIEW (CIRCULAR DUCTS VERSION)
TOP VIEW
LEFT SIDE VIEW
RIGHT SIDE VIEW
N. 8 slots 9x12---
unit fixing
N. 2 collars
ø200 H=35 mm
Refrigerant connection
Electrical
connection
803
70994
14.5
120,5 562 120,5
59 192 59
310
803 28,528,5
FRONTVIEW(RECTANGULARDUCTVERSION)
Refrigerant connection
Collar
190x560 H=35 mm
860
