Liebert HPSE User Manual

Dimensional Drawings
Liebert HPS---PD--- 272965---20.11.2009
8--7
Fig. 10 --- Evaporating unit SE 08-- 10-- 13-- 14W (version with freecooling)
Condensate drainCondensate drain
Refrigerant inlet Refrigerant inlet
295
1100
32090 320320
50
395 395
220 175220 175
95 50
N.2 COLLARS 4 250 HEIGHT 35 mm
N.8 HOLES 4 8
310 350 395
250
185 600 270
1395
30 1055 30
395
COLLAR 250 X 600 HEIGHT 35 mm
Circular ducts version Rectangular duct version
BOTTOM VIEW
REAR VIEW SIDE VIEW
TOP VIEW
BOTTOM VIEW
Electrical connections
Refrigerant outlet Refrigerant outlet
