Liebert HPSE User Manual

Installation
9--7
Liebert HPS---PD--- 272965---20.11.2009
F i g . 2 1 --- HPSC 06-- 08-- 10-- 12-- 14 service a nd w orking area
1
3
4
5
2
If H1 < 0.5 x H2 ⇒ L mi n. = 500 mm.........
If 0.5 x H2 ≤ H1 ≤ H2 ⇒ L min. = 800 mm...
If H1 > H2 ⇒ Not allowable configuration..............
5
WALL IN FRONT
OF UNITS
WALL IN FRONT
OF UNITS
WALL BEHIND
UNITS
WALL BEHIND
UNITS
M U LT I --- R O W S
INSTALLATION
