Liebert HPSE User Manual

Model Description and Selection
2--3
Liebert HPS---PD--- 272965---20.11.2009
Model Nomenclature / Digit Numbers
6
4
10987
1 2
HPSC06
Cooling Capacity “kW”
(Nominal Cooling C apacity)
Split Condenser Section
(Outdoor Unit)
High Performance Unit
3 5
OUTDOOR UNIT
HPSC 06 --- 14
BASE UNIT CONDENSER SECTION
Split air cooled outdoor unit
Digits 1, 2, 3, 4, 5, 6
D Scroll compressor
D R407C --- 230V / 1Ph / 50Hz (6kW)
D R407C --- 400V / 3Ph / 50Hz (8--- 14kW)
D RAL7035 ”bright grey” cabinet
Digit 7 --- Configuration
0 = Base (no sight glass filter, ON--- OFF fan speed control)
A =Advanced
D Sight glass filter, modulating fan speed control, lower
noise, higher external temperature
L = Long piping application
D i g i t 8 --- C o n d e n s e r c o i l
0 = Standard aluminium fins
1 = Epoxy coated condenser fins
2 = Standard aluminium fins with protection grilles
3 = Epoxy coated condenser fins with protection grilles
D i g i t 9 --- P a c k i n g
0 = Pallet + heavy cardboard
C = Cardboard and wooden crate
S =Seaworthy
Digit 10 ---Special requirements
0 =None
X =Special
