Lifepro READY, SET, PRO - Page 7

SECURE THE SEAT TO THE
SEAT POST
1. Lay the seat (10) on the floor, underside up.
2. Use the multi-tool (40) to remove the three flat washers (11) and three
nuts (12) from the seat (10).
3. Lay the seat on the floor, underside up.
4. Slide the seat post (13) onto the three integrated bolts on the
underside of the seat.
5. Place a flat washer (11) onto each bolt.
6. Screw a nut (12) onto each bolt.
7. Use the multi-tool to fully tighten the three nuts.
3
Endurance Training Collection 13 12 VeloCycle User Manual Lifepro Endurance Training Collection 13
ATTACH THE BACKREST
TO THE SEAT AND BACKREST FRAME
1. Remove four bolts (18) and four flat washers (19) from the rear of the
seat and backrest frame (17).
2. Place a flat washer (19) onto each bolt (18).
3. Insert each bolt/washer combination through the BACK of the four bolt
holes in the seat and backrest frame (17) and into the bolt holes in the
backside of the backrest (16).
4. Use the 4mm hex key (41) to tighten each bolt.
4
(12)
(11) x3
x3
TOOLS & HARDWARE
(40)
12
11
18
19
16
17
10
13
(19)
(18)
(41)
x2
x4
(4mm)
TOOLS & HARDWARE
