LifeSafety Power FlexPower C8P User Manual

C4,C4P / C8, C8P Installation Manual
8 9
Common Jumper Settings
Jumper
xA (red) xB (blue) xC (black) xD (yellow) xE (black) xF (white)
Continuous Auxiliary Output (No zone control input)
With FAI 1 2 2 Note 1 2 2
Without FAI 2 2 2 Note 1 2 2
Maglock Output
NC Contact Input - with FAI 1 1 2 Note 1 2 2
NC Contact Input - without FAI 2 1 2 Note 1 2 2
NO Contact Input - with FAI 1 2 2 Note 1 2 2
NO Contact Input - without FAI 2 2 2 Note 1 2 2
Voltage Input - with FAI 1 1 2 Note 1 2 2
Voltage Input - without FAI 2 1 2 Note 1 2 2
Transistor Input - with FAI 1 1 2 Note 1 2 2
Transistor Input - without FAI 2 1 2 Note 1 2 2
Door Strike Output
NC Contact Input - with FAI 1 1 2 Note 1 2 1
NC Contact Input - without FAI 2 1 2 Note 1 2 1
NO Contact Input - with FAI 1 2 2 Note 1 2 1
NO Contact Input - without FAI 2 2 2 Note 1 2 1
Voltage Input - with FAI 1 1 2 Note 1 2 1
Voltage Input - without FAI 2 1 2 Note 1 2 1
Transistor Input - with FAI 1 1 2 Note 1 2 1
Transistor Input - without FAI 2 1 2 Note 1 2 1
NC Relay Output (Note 2)
NC Contact Input - with FAI 1 1 1 N/A 1 2
NC Contact Input - without FAI 2 1 1 N/A 1 2
NO Contact Input - with FAI 1 2 1 N/A 1 2
NO Contact Input - without FAI 2 2 1 N/A 1 2
Voltage Input - with FAI 1 1 1 N/A 1 2
Voltage Input - without FAI 2 1 1 N/A 1 2
Transistor Input - with FAI 1 1 1 N/A 1 2
Transistor Input - without FAI 2 1 1 N/A 1 2
NO Relay Output (Note 3)
NC Contact Input - with FAI 1 1 1 N/A 1 1
NC Contact Input - without FAI 2 1 1 N/A 1 1
NO Contact Input - with FAI 1 2 1 N/A 1 1
NO Contact Input - without FAI 2 2 1 N/A 1 1
Voltage Input - with FAI 1 1 1 N/A 1 1
Voltage Input - without FAI 2 1 1 N/A 1 1
Transistor Input - with FAI 1 1 1 N/A 1 1
Transistor Input - without FAI 2 1 1 N/A 1 1
Note 1 - Set Jumper D according to which input voltage source (B1/B2) should be directed to the output
Note 2 - Relay OPENS when the input is activated
Note 3 - Relay CLOSES when the input is activated
