LifeSpan CHASER User Manual

27
CHASER
NO.
DESCRIPTION
SPEC.
QTY
NO.
DESCRIPTION
SPEC.
QTY
1
Main frame
1
39
Magnet Ring
1
2
Base frame
1
40
Brown Single Wire
1
3
Upright bracket
2
41
Computer Control board
1
4
Computer bracket
1
42
Computer bottom wire
1
5
Motor Bracket
1
43
Computer up wire
1
6
Running board strengthening tube
2
44
Rubber pad 2
2
7
Rubber pad
4
45
Moving wheel cover
2
8
Cylinder
1
46
EVA mat 2
150*20*3
2
9
Front roller
1
47
Bolt
ST4.2*13
5
10
Rear roller
1
48
Screw
M8*25
1
11
EVA mat 1
400*20*5
2
49
Bolt
M8*42
1
12
#5 Allen wrench
5mm
1
50
Bolt
M8*25
1
13
Start/stop pulse key
1
51
1 Lock nut
M6
10
14
DC Motor
1
52
Bolt
ST4.2*45
2
15
Running board
1
53
Bolt
M6*30
4
16
Adjustable foot Pad
2
54
Bolt
M6*35
4
17
Inner circle end
2
55
Bolt
M8*16
10
18
Motor up cover
1
56
Bolt
M6*65
3
19
Motor bottom cover
1
57
Bolt
M8*40
2
20
Side Rail
2
58
Bolt
M10*55
2
21
Right Back End Cover
1
59
Flat Washer
8
7
22
Left Back End Cover
1
60
Bolt
ST4.2*12
7
23
Fixing plug
2
61
Bolt
M5*8
1
24
Motor belt
1
62
1 Lock nut
M8
6
25
Power wire buckle
1
63
Lock washer
10
2
26
Running belt
1
64
Standard spring washer
8
6
27
Foot pad
4
65
Standard spring washer
5
1
28
Ring wire plug B
2
66
Bolt
ST4.2*19
12
29
Transport wheel
2
67
Lock washer
8
10
30
Speed pulse +-Key
1
68
Lock washer
6
3
31
Standard power wire
1
69
Lock washer
5
1
32
Power switch
1
70
Bolt
M8*45
4
33
Foam
2
71
MP3wire
1
34
Computer cover
1
72
Bolt
ST4.2*20
4
35
Computer face panel
1
73
Bolt
ST4.2*30
2
36
Bolt
M6*37
2
37
Oil Bottle
1
38
Safety key
1
10. PARTS LIST
