12
Step 1: Unpacking Treadmill
A. Cut packaging straps and
remove.
B. Remove the box top.
C. Remove small parts and
packaging material and
unwrap parts.
D. Cut the corners of the bottom box and remove all packaging material to
begin assembly. The treadmill can be assembled in the box. No need to pick
the treadmill up to remove it from box.
Step 2: Upright Post Attachment
A. Carefully fold the uprights
with handlebars up into the
upright position.
B. Carefully lay handlebars
down as the uprights are
brought up into position.
This will protect against any
accidental damage to wires
coming up through the
upright into the handlebars.
C. Align the holes in the lower
portion of the upright with
the threaded holes in the
frame.
D. Install the four M10 x 45L
bolts (9) and M10 washers
(10), two in each upright. The
best way to handle this is to
loosely install all four bolts
and washers and then tighten
once all bolts are installed.
Assembling Your Treadmill
Support
handlebars
as you lift
M10 x 45L
(x4)
M10 Washer
(x4)
6mm Allen
Wrench
To Next Page
