VIPER
9. PARTS LIST
NO.
DESCRIPTION
SPEC.
QTY
NO.
DESCRIPTION
SPEC.
QTY
1
Main frame
1
51
Magnet Ring
1
2
Base frame
1
52
Power Switch
1
3
Left upright
1
53
Power Line
1
4
Right upright
1
54
Overload protection
1
5
Computer Bracket
1
55
AC Single Wire
1
6
Incline Bracket
1
56
Blue Single Wire
1
7
Motor Bracket
1
57
Brown Single Wire
1
8
Rotating pipe
2
58
Power cord jack
1
9
Cylinder
1
59
Lock nut
M10
4
10
Front roller
1
60
Lock nut
M8
12
11
Rear roller
1
61
Bolt
M8*25
2
12
wrench w/screw driver
S=13、14、15
1
62
Bolt
M8*48
5
13
#5 Allen wrench
5mm
1
63
Bolt
M6*16
4
14
#6 Allen wrench
6mm
1
64
Bolt
M8*32
4
15
Spring cushion
8
65
Bolt
M8*55
3
16
Running board
1
66
Bolt
M8*12
2
17
Left back cover
1
67
Bolt
M8*20
10
18
Right back cover
1
68
Bolt
M10*65
2
19
EVA pad
30*47*2
4
69
Bolt
M4*50
2
20
Side Rail
2
70
Bolt
M8*55
5
21
Running Belt
1
71
Bolt
M10*42
3
22
Motor Cover
1
72
Bolt
M10*60
1
23
Left Upright Cover
1
73
Bolt
M8*40
2
24
Right Upright Cover
1
74
Bolt
M6*40
1
25
pul-out piece spring
8
75
Bolt
ST4.2*19
20
26
Torsion Spring
1
76
Lock nut
M6
1
27
Hollow casing pipe
1
77
Bolt
ST4.2*12
10
28
Adjustable wheel
2
78
Bolt
ST2.9*6.5
2
29
Taper Cushion
2
79
Bolt
ST4.2*12
20
30
Rotating pipe
2
80
Bolt
ST4.2*55
2
31
Right base cover
1
81
Bolt
ST4.2*13
25
32
Left base cover
1
82
Lock Washer
10
4
33
Ring wire plug
2
83
Flat Washer
8
10
34
Hand pulse
2
84
Spring washer
8
6
35
Transport wheel
2
85
Lock washer
5
3
36
Face panel
1
86
Lock washer
8
21
37
Drive belt
1
87
Bolt
ST4.2*19
6
38
Motor bottom cover
2
88
Bolt
ST4.2*20
8
39
Left handle bar
1
89
Foot pad
4
40
Right handle bar
1
90
EVA
4
41
Incline Motor
1
91
IPAD rack
1
42
DC Motor
1
92
Fan blade
5
43
Computer top cover
1
93
Filter
1
44
Control board
1
94
Inductor
1
45
Computer bottom cover
ST4.2*12
2
95
CE fix board
1
46
Oil Bottle
1
96
Wind scooper
1
