LifeSpan VIPER - Assembly Instructions

6
VIPER
 Do not use excessive pressure on console control keys. They are precision set to function properly
with little finger pressure.
 Replace any defective components immediately. The machine must be kept out of use until fully
repaired
4. ASSEMBLY INSTRUCTIONS
PARTS LIST
NO.
Description
Specification
Qty
NO.
Description
Specification
Qty
1
Main frame
1
67
Bolt
M8*20
8
12
Allen Wrench
S=13\14\15mm
1
70
Bolt
M8*55
2
13
5#Allen Wrench
5mm
1
86
Lock washer
8
10
14
6#Allen Wrench
6mm
1
75
Screw
ST4.2*19
6
32
Left base cover
1
88
Screw
ST4.2*20
2
31
Right base cover
1
53
Standard Power Line
1
49
Safety key
1
100
Mp3 Wire
1
ASSEMBLY TOOLS:
