STEP 1:
1. Open the carton
2. Extract the parts listed above
3. Place the Main Frame onto level ground
Warning: Use 2 people to remove treadmill from the box to avoid accidents.
STEP 2:
1. Fold the treadmill upright as shown above. You will need a second person to hold the treadmill
upright while you assemble it.
2. Secure the Right/Left upright (4L) (5R) to the base frame with:
- 2pcs M8*20mm bolt (88)
- 2pcs φ8 washer (87)
- 4pcs M8*60mm bolt (12)
- 4pcsφ8 flat washer (29)
- 4pcs lock nut (27)
3. Connect the Right/Left upright (4L) (5R) with the base frame (1) and tighten bolts.
4. Check the upright is tighten, then use 2pcs bolt (25) to secure the Right/Left base cover (54L)
(55R) on the Right/Left upright (4L) (5R).
To Next Page
