AM-HLTMC-OM
Rev AA January 2018
Condition Charge
Set conditional charge %.
The charger will only commence the charge if the battery has reached the limit of depth
of discharge (DoD) of more than x%. For example if the user wants to charge the
battery only if it is discharged more than 30%, the parameter 30 has to be entered in the
conditional charge. The 0 value disables the function.
Battery Rest
Set battery rest time in hours
Refresh On/Off
Sets refresh mode on or off.
Once charging is complete, as long as the battery remains connected, refresh charging is
automatically initiated to retain the battery’s charge.
Battery
NB Cells
Sets number of battery cells: 6,12,18, 24, 36, 40, AUTO
Cap Man/Auto
When in Ionic mode, the charger can estimate the capacity of the connected battery
automatically “Auto” or the charger will use the capacity entered manually “Manu” in the
Capacity menu.
Capacity
Without BBWC: this adjusts the battery AH capacity used by the charger to determine start
and finish rates, and will match the AH capacity of the battery being charged.
With BBWC: the battery AH capacity will be automatically transmitted from BBWC.
Battery Temperature
This parameter adjusts the regulation voltages on the charging profile (values between –
15°C / 5°F and 65°C / 149°F).
Without BBWC: defines the average operating battery temperature before the charge. It is
recommended the average electrolyte temperature be entered, especially in cold areas.
With BBWC: the battery operating temperature will be automatically transmitted from
BBWC. The battery temperature will be analyzed during the charge; if it increases too much,
the charger will stop to prevent any possible damage.
High temperature
Defines a battery temperature safety limit.
Without BBWC: not used.
