AM-HLTMC-OM
Rev AA January 2018
With BBWC: If the battery temperature, during the charge, reaches the programmed limit,
the charger will stop the charge and wait until the temperature decreases.
LM/EB
Late Make / Early Brake option (extra wire from the backplane to the auxiliary contact of the
DC plug)
Cable
Length
Select the length of DC cables from the charger to the battery terminals in 1 foot increments
from 4 to 49 ft .
Section
Sets the DC cable gauge. Selections are 10, 8, 6, 4, 2 awg, 1/0, 2/0
Equalization
Manu Current
This defines the equalization or desulphation current for a manual start.
Time
Sets the equalization time from 1 to 48 hrs
Delayed start (delay)
Sets the delay between the normal charge and the equalization charge from 0 hr to 23 hrs.
Frequency
Selects one or several periods for carrying out the equalization charge. The user can select
one or several days per week.
Option
Options Test
Turns on Battery Status (Red/Green) and Electrovalve output briefly to test operation.
Electroval Time
Sets the time the Electrovalve output will be on (0 to 299 seconds) after charge is complete.
Network
Protocol
Select the type of data connection: Jbus (used only by the factory), LAN, BFM.
Baud Rate
Select the speed of the data connection (The values for these settings will depend on the
