Lifetime 1270 User Manual

11
POLE ASSEMBLY
HARDWARE REQUIRED
PARTS REQUIRED
TOOLS REQUIRED
SEC
1
Parts shown at 10% of Actual Size
Phillips Screwdriver
Hardware shown at Actual Size
3CRAP7OOD
ALH (x1)
Top Pole
!,& (x1)
Middle Pole
ALE (x1)
Bottom Pole
7ARNING3TICKERAPPLIEDTOSIDENOTSHOWN
ADS (x1)
1/4” x 3/4” Screw
AAN (x1)
5/16” Cap Nut
AYT (x1)
5/16” Hex Nut
AOL (x2)
5/16” x 3 1/4” Carriage Bolt
ABD (x1)
5/16” Washer
AYU (x1)
5/16” Hex Knob
*Do not remove Top Pole from Middle Pole until instructed
7RENCH
CIH (x1)
Domed Countersink Washer
Part shown at 25% of Actual Size Part shown at Actual Size
