Lifetime 1270 - Hardware Identifier

9
ABN (x2)
1/2” x 1/8” Spacer
HARDWARE IDENTIFIER
0/,%!33%-",9(!2$7!2%
Hardware shown at Actual Size
"!#+"/!2$4/0/,%!33%-",9(!2$7!2%
Hardware shown at Actual Size
0/,%4/"!3%!33%-",9(!2$7!2%
Hardware shown at Actual Size
ADS (x1)
1/4” x 3/4” Screw
AAN (x1)
5/16” Cap Nut
AYT (x1)
5/16” Hex Nut
AOL (x2)
5/16” x 3 1/4” Carriage Bolt
ABD (x1)
5/16” Washer
AAE (x2)
5/16” x 1” Hex Bolt
AAO (x2)
5/16” Nylock Nut
BTS (x1)
1/4” Barrel Nut
ABD (x4)
5/16” Washer
CII (x1)
1/4” x 2 3/4” Shoulder Bolt
!0' (x2)
5/16” x 3 1/4” Hex Bolt
AAC (x2)
5/16” x 1 3/4” Hex Bolt
ABD (x4)
5/16” Washer
ABK (x4)
5/16” Nylock Flange Nut
