Parts shown at 5% of Actual Size
PARTS IDENTIFIER
!*) (x1)
Backboard
!*- (x1)
Base
AYU (x1)
5/16” Hex Knob
AMU (x2)
Wheel
!%& (x2)
Base Plug
Part shown at 25% of Actual Size
CIH (x1)
Domed Countersink Washer
Parts shown at Actual Size
AOX (x1)
Rim Support Channel
