Lifetime 1270 - Parts Identifier

7
Parts shown at 10% of Actual Size
ALH (x1)
Top Pole
!,& (x1)
Middle Pole
ALE (x1)
Bottom Pole
PARTS IDENTIFIER
!** (x1)
,EFT"ACKBOARD"RACKET
!*+ (x1)
Right Backboard Bracket
!*# (x1)
1/2” x 15 3/4” Axle
15 ”
3/4
7”
!*% (x1)
1/2” x 7” Axle
7ARNING3TICKERAPPLIEDTOSIDENOTSHOWN
ALI (x2)
Pole Brace
*Do not remove Top Pole from Middle Pole until instructed
ALX (x1)
Rim
AKZ (x1)
Net
