POLE TO BASE ASSEMBLY
HARDWARE REQUIRED
PARTS REQUIRED
TOOLS USED (NOT INCLUDED)
SEC
2
Parts not shown to scale
Parts shown at actual size
AAS (x1)
1/4”-20 x 2 3/4” Hex Bolt
AZW (x2)
1/4”-20 x 5 1/2” Carriage Bolt
AZU (x1)
1/2” x 1.9” Metal Spacer
AZP (x3)
1/4”-20 Nylock Nut
AZM (x1)
Base
AZX (x1)
Base Plate
7/16” Wrench (x2)Safety Glasses
AZS (x2)
Split Collar
