Lifetime 90046 - Goal Adjustment and Net Securing; Adjusting to 6 x 4 Size; Adjusting to 4 x 3 Size

7
At full size, the Soccer Goal will measure 7’ wide and 5’ tall. To adjust
the size to 6’ x 4’, press the push buttons on the top and rear assembly
legs and slide the goal to the middle hole on each tube. Press the
push buttons on the side legs and slide the goal to the middle holes
on each tube.
Step
2.1a
To adjust the size to 4’ x 3’, press the push buttons on the top and rear
assembly legs and slide the goal to the far left hole on each tube. This
will adjust the width. Press the push buttons on the side legs and
slide the goal to the bottom holes on each tube to adjust the height.
Step
2.1b
Bottom Hole
GOAL ADJUSTMENT
SEC
2
Push Buttons
Push Buttons
Middle Hole
Push Buttons
Middle Hole
Push Buttons
Far Left Hole
