Lifetime 90046 - Goal Setup Instructions; Step 1.1: Remove Storage Straps; Step 1.2: Swing Out and Lock Legs

4
Remove the Storage Straps (BZF) from the Adjustable Goal and Net Assembly (BZE).
Step
1.1
Swing the legs out as pictured. Lock the legs into place using the
Locking Pins on the four corner brackets shown.
Step
1.2
BZF
GOAL SETUP
SEC
1
Note: Do not carry the Adjustable Goal and Net Assembly by the Storage Straps.
When folded up, always carry the goal by holding the metal tubing.
!
BZF
BZE
Note: The Net should remain attached to the Assembly. It has been
omitted from these images in order to clarify parts handled during setup.
!
BZE
Locking Pin on
Corner Bracket
Note: If the Locking Pin is difficult to insert, turn the Pin so the ball on the Pin
slips through the hole sideways. Jiggle the tubing while pushing the Pin through
to line up all holes.
!
