20
TOOLS AND HARDWARE REQUIRED
X SECTION 2 (CONTINUED)
Dimpled hole
2.4
• Make sure the dimpled holes on each assembly face opposite directions. These dimpled holes will need to face the
outside of the Fuselage.
Dimpled hole
2.3
DXX
DXX
CVZ
CVZ
ATB
ATB
ATB (x4)
CVZ (x4)
DXX (x4)
• Secure the Fuselage assembled in Sec 2.2 with the hardware shown. Make sure to insert the T-Nuts (ATB) so they
face the opposite side of the assembly as the dimpled holes in the tubes. Repeat this step with the hardware in the
reverse direction to complete the other Fuselage frame.
3/16 in/po (≈5 mm)
(2)
