STANDARD BASE AND STABILIZERS
Item
Number
Part
Number
Description
Quantity
1
M00014
Base Weldment
1
---
M00070
Stabilizer Option*
(includes 2 stabilizer assemblies and all mounting hardware except M00075)
2
M00075
Stabilizer Latch Mounting Plate
1
3
M00079-
ASSY
Stabilizer Brace Tube w/Roll Pin Assy
2*
4
M00078
Stabilizer Latch Tube
2*
5
M00077
Stabilizer Latch Plate
6*
6
M00131
Stabilizer Pivot Tube
2*
7
M00700
HHCS - M12 x 80
2 + 2*
8
M00707
Washer - M12
4*
9
M00701
Hex Nut - M12
2 + 2*
10
M00490
HD Caster - 5” x 2" w/Side Brake
2
11
M00088
Leg Locking Pin w/ Lanyard (ball detent pin)
2
12
M00071
Stabilizer Weldment
2*
13
M00740
HHCS - M10 x 30
10
14
M00750
Washer, Lock - 1/2”
2*
15
M00704
HHCS - M10 x 50
2*
16
M00706
Hex Nut - M10
14 + 4*
17
M00705
HHCS - M10 x 70
2*
18
M00743
Washer - M10
20 + 8*
19
M00076
Caster 1.5” x 3 1/2” - Stabilizer
2*
20
M00749
Jam Nut - 1/2-13
2*
21
M00740
HHCS - M10 x 30 ¹
4
M00739
HHCS - M10 x 35 ¹
22
M00711
Washer - M12 - Fender
4*
23
M00052
Stabilizer Latch Spring
2*
* Notes: Stabilizers and related components (quantities denoted above with *) are optional equipment on the
MLC-12 model. Verify whether the MLC Construction Pro model is equipped with stabilizers before beginning
maintenance or ordering replacement parts.
¹ In most cases, the bolts used to attach the base to the mast mounting plate are M00740 but, in some cases,
a quantity of two or four M00739’s are used instead, if there are washer shims placed between the mast and
the base plate to obtain the specified mast tilt-back required for the various MLC models produced (see page
16 for more information on tilt-back).
