CLEANING THE MASTS
LiftSmart requires that this procedure be performed
every 200 hours or quarterly, whichever comes
first.
Perform the following steps to clean the masts:
❑ Raise the material lift to its maximum height.
❑ Visually inspect the inner and outer roller wheel
channels of each mast for foreign material or
debris.
❑ As needed, clean the channels of each mast
using a mild cleansing agent.
When cleaning the masts, NEVER:
❑ Lubricate the masts.
❑ Apply an additional side load or horizontal force
to a material lift that is loaded and/or raised.
❑ Place ladders or scaffold against the material
lift.
INSPECTING THE WINCH
(Refer to winch diagram in Section 5 - Parts)
❑ Raise the Fork Carriage halfway to ensure the
winch is operating correctly.
Result: The winch should operate smoothly.
❑ Lower the Fork Carriage.
Result: The winch should operate smoothly.
If winch is not operating properly, perform the
following inspections on the winch:
❑ Inspect the brake lining plates for excessive
wear.
▪ Replace the brake lining plate if it is less
than 1/16 inch (1.5 mm) thick.
❑ Inspect the reamed bushings on the shaft for
excessive wear.
▪ Replace the reamed bushing if the wall
thickness is less than 1/8 inch (3.1 mm).
❑ Inspect the winch assembly for loose,
damaged, or missing fasteners.
▪ Tighten or replace fasteners as needed.
▪ Tighten the 3/8-16 lock nut that attaches
the reel assembly to 20 ft-lb (27 N*m).
▪ Do not over tighten fasteners.
LUBRICATING THE WINCH
Lubricate the gears on the following components of
the winch using automotive grease:
❑ The reel assembly.
❑ The ratchet wheel.
❑ The primary shaft assembly.
❑ The intermediate shaft assembly (2-speed
winch models).
ADDITIONAL WINCH LUBRICATION
Lubricate the following winch components with the
lubricant listed:
❑ Lubricate the ratchet pawls with 30W oil.
❑ Lubricate the reel spacer with automotive
grease.
Injury hazard. This procedure may
require the use of additional access
equipment. Do not place ladders or
scaffolding against the machine.
Performing this procedure without
the proper skills and tools may
result in serious injury or death.
Dealer service is recommended.
