LiftSmart MLC - Page 47

MLC Construction Pro Series
Part Number M00969C
Parts & Service Manual
Copyright © 2022 LiftSmart
45
MAST ASSEMBLY (III) - FRONT MAST AND FORK CARRIAGE
2011 - 2012 MODELS
Item
Number
Part
Number
Description
Quantity
1
M00038
MLC Mast B Standard and Mast Brake Models ¹
1
2
M00060
Pulley w/Bearing
3
3
M00054
Pulley Mount - 1/2-13
3
4
M00048
Pulley Guard
3
5
M00707
Washer - M12 - Narrow
14
6
M00716
HHCS - M12 x 30
2
7
M00710
HHCS - M10 x 20 ²
6
8
M00706
Hex Nut - M10
7
9
M00061
Up Stop
3
10
M00062
Down Stop
3
11
M00714
FHCS - M10 x 40 ³
6
12
M00051
Roller Guard
2
13
M00042
Roller Bolt - SHCS - M12 x 19, 1/2" Shoulder
6
14
M00701
Hex Nut - M12
9
15
M00043
Roller
6
16
M00065
Cable End Weldment
1
17
M00040
Fork Carriage Standard ¹
1
18
M00746
Lock Washer - M10 ²
8
19
M00754
Washer - 1/2” - Hardened
4
20
M00058
Reinforcement Block
4
21
M00715
HHCS - M12 x 40
1
22
M00740
HHCS - M10 x 30
3
23
M00743
Washer - M10 - Flat
2
24
M00753
HHCS - 1/2-13 x 1 1/2" ⁴
1
25
M00711
Washer - M12 Fender
1
26
M00752
HHCS - 1/2-13 x 1 1/4” ⁴
2
27
M00756
FHCS - M10 x 35
6
¹ Mast Brake Models were not produced in 2011 - 2012. Please see next page for parts diagram and table
for mast brake models.
² Models produced in 2011 and 2012 used M00710 and M00746 because M00446 was not yet used in the
mast design. The M00446 Mast Reinforcement plate was implemented in 2013 and required the longer
M00713 bolt (see next table). The M00710 bolts and M00746 lock washers were discontinued.
³ Recommend using blue thread sealant for these fasteners.
⁴ Torque to specifications and use red thread sealant for these fasteners.
