LiftSmart MLC - Page 53

MLC Construction Pro Series
Part Number M00969C
Parts & Service Manual
Copyright © 2022 LiftSmart
51
Item
Number
Part
Number
Description
Quantity Per Winch Assembly
---
M00113-
ASSY
2-Speed Winch Assy w/Decals (NO HANDLES)
1
M00800
Reel/Drum
1
2
M00801
Reel Cover
1
3
M00802
Reel Spacer
1
4
M00803
Gear Cover
1
5
M00804
Thread Forming Screw - 1/2”
2
6
M00805
Brake Spring Spacer
2
7
M00806
E-Ring - 3/4"
1
8
M00807
HHCS - 3/8-16 x 1 1/2
2
9
M00808
Washer - Flat - 3/8”
2
10
M00809
Ratchet Pawl Assembly
2
11
M00810
Ratchet Spring
2
12
M00811
Ratchet Spacer
2
13
M00812
Nut, Lock 3/8-16
3
14
M00813
Reel Bolt Lock
1
15
M00814
HHCS - 3/8-16 x 5 1/2
1
16
M00815
Brake Hub Assembly
1
17
M00816
Break Lining Plate
2
18
M00817
Ratchet Wheel
1
19
M00818
Washer - Double D
1
20
M00819
Spacer
1
21
M00820
Sintered Iron Bearing
1
22
M00821
Nut, Hex Lock - 5/8-11
3
23
M00837
6” Offset Handle Assembly (MLC-12 Models)
2
M00822
8” Offset Handle Assembly (MLC-18 & MLC-24 Models)
2
24
M00831
Reamed Bushing
1
25
M00824
Base
1
26
M00825
Detent Spring
2
27
M00826
Chrome Ball
2
28
M00827
Nut, Hex Lock - 1/4-20
3
29
M00840
HHCS - 1/4-20 x 1 1/2
2
30
M00829
Base Spacer 3/8 x 4 3/8
1
31
M00842
HHCS - 1/4-20, 5 3/16
1
32
M00831
Reamed Bushing
2
33
M00832
Intermediate Shaft Assembly
1
34
M00833
Detent Block
1
35
M00834
Rope Clamp Kit
1
36
M00835
Washer - Flat - 15/16
1
37
M00836
Primary Shaft Assembly
1
38
M00905
Decal, 2-Speed Winch (not depicted)
1
39
M00908
Decal, Winch Only Use For Specific Models (not depicted)
1
40
M00909
Decal, Crushing Hazard / Brake Lock (not depicted)
1
