LiftSmart MLC - Page 55

MLC Construction Pro Series
Part Number M00969C
Parts & Service Manual
Copyright © 2022 LiftSmart
53
SMART-LATCH™ OPTION
Item
Number
Part
Number
Description
Quantity Per Machine
MLC-12
MLC-18
MLC-24
---
M07180
Smart-Latch™ Assembly - 2 Stage Mast
1
---
M00181
Smart-Latch™ Assembly - 3 Stage Mast
1
---
M00174
Smart-Latch™ Assembly - 4 Stage Mast
1
Quantity Per Assembly
Item
Number
Part
Number
Description
2-stage
3-stage
4-stage
M07180
M00181
M00174
1
M00178
Smart-Latch™ Catch
1
1
1
2
M00734
Bolt, SHS 10 x 12mm ZP
2
2
2
3
M00703
Hex Nut - M8
4
4
4
4
M00709
Washer - 0.4” ID x 1.0 OD x 0.05” - Nylon
1
1
1
5
M00177
Smart-Latch™
1
1
1
6
M00747
HHCS - M6 x 25
4
4
4
7
M00706
Hex Nut - M10
4
4
4
8
M06451
Smart-Latch™ Arm - 2 Column
1
0
0
M06452
Smart-Latch™ Arm - 3 Column
0
1
0
M06453
Smart-Latch™ Arm - 4 Column
0
0
1
M06454
Smart-Latch™ Arm - 5 Column
0
0
0
9
M00748
Hex Nut - M6
4
4
4
---
M00185
Manual Storage Tube Assembly
1
1
1
10
M00188
Clamp - Manual Storage Tube
2
2
2
11
M00187
Manual Storage Tube Cap
2
2
2
12
M00186
Manual Storage Tube
1
1
1
13
M00740
HHCS - M10 x 30
4
4
4
14
M00743
Washer - M10 - Flat
7
7
7
15
M00173
Smart-Latch™ Bracket 1 Column
0
0
0
M06450
Smart-Latch™ Bracket 2 - 5 Column
1
1
1
16
M00723
FHCS - M8 x 20
2
2
2
17
M00900
Decal, Manual Storage Tube
1
1
1
M00900CE
Symbolic Decal, Manual Storage Tube (for international models)
