MLC Construction Pro Series
Part Number M00969C
Parts & Service Manual
Copyright © 2022 LiftSmart
63
PIPE CRADLE ACCESSORY
Item
Number
Part
Number
Description
Quantity Per Set
---
M00270
Pipe Cradle Accessory (includes all components below)
1
M00271-
ASSY
Pipe Cradle Forming w/Decals
2
2
M00730
Wing Nut - M12
4
3
M00731
HHCS - M12 x 60
4
4
M00910
Decal, Warning No Riders
2
M00912CE
CAUTION Read the Manual, Symbolic (for international models)
5
M00750
Washer, Lock - 1/2”
4
6
M00707
Washer, Flat - M12
4
7
M00951
WARNING - No Riders SYMBOL (for international models only)
FORK EXTENSION ACCESSORY
Item
Number
Part
Number
Description
Quantity Per Set
---
M00159
Fork Extensions Accessory (includes all components below)
1
M00163
Fork Extension Tube
2
2
M99988
Pin - Detent - 0.5” x 2.5”, no lanyard
2
MANUAL STORAGE TUBE ASSEMBLY
Item
Number
Part
Number
Description
Quantity Per Set
---
M00185
Manual Storage Tube Assembly (includes all components below)
1
M00186-
ASSY
Manual Storage Tube w/Decal
1
2
M00187
Manual Storage Tube Cap
2
3
M00188
Clamp - Manual Storage Tube
2
4
M00747
HHCS - M6 x 25
2
5
M00748
Hex Nut - M6
2
6
M00900
Decal, Manual Storage Tube (North American and English language models)
1
M00900CE
Decal, Manual Storage Tube, Symbolic (for international models)
CABLE ASSEMBLIES (NOT SHOWN IN DIAGRAMS)
Quantity Per Machine
MLC-12
MLC-18
MLC-24
---
M00286
Cable Assembly, MLC-12
1
0
0
---
M00127
Cable Assembly, MLC-18
0
1
0
---
M00282
Cable Assembly, MLC-24
0
0
1
