Lightware DVI-TP-TX200DL User Manual

Page 6 / 29
1. Introduction
Dear Customer,
Thank you for choosing Lightware DVI-TP series transmitters and receivers. DVI-
TP-TX200DL and DVI-TP-RX100DL are Dual Link DVI over Twisted Pair extenders
which allow video signals of up to 3840x2400@30Hz resolution to be transmitted
through 50 meters of high quality CAT7 cables.
2. General description
2.1. Box contents
− DVI-TP-TX200DL or DVI-TP-RX100DL
− User's manual
− Quick Start Guide
− +5V wall plug universal AC power adaptor
2.2. Transmitter features (DVI-TP-TX200DL)
 Advanced EDID Management – The user can emulate any EDID on the DVI-TP-
TX200DL’s input, read out and store any monitor's EDID
(attached to Monitor Output) in 49 internal memory locations.
Green and red EDID status LEDs show whether a valid address
is selected.
 Supports highest resolutions – 2048x1536p 60 Hz, 2560x1600p 60 Hz, and
3840x2400p 30 Hz are supported including all standard HDTV
resolutions (720p, 1080i, 1080p). Unencrypted signals up to
330 MHz pixel clock frequency (up to 165 MHz TMDS clock
frequency) regardless of the resolution are passed through.
 Source and Monitor Connected LEDs – Two LEDs indicate when a DVI source
and display device is connected to the DVI-TP-TX200DL: the
source is sending +5V signal and the display is sending Hot
Plug signal.
 Local Monitor Output – The user can attach a local monitor with a dual link DVI
cable to observe the video signal sent through the CATx cables.
The resolution and clock frequency are the same on DVI and
RJ45 connectors, no internal scaling or conversion is applied.
 Front panel control – EDID Address selection with two decimal rotary switches
and Learn EDID button are available for Advanced EDID
Management.
 Fiber cable support – Self powered DVI fiber cables or converters using +5V from
DVI sources (VGA cards, etc.) usually consume more than 55
mA, which load is the maximum allowed by DVI 1.0 standard.
DVI-TP-TX200DL supports +5V/500 mA constant current output
on MONITOR OUTPUT to power long distance fiber optical
transmitters.
 Universal power adaptor – DVI-TP-TX200DL is equipped with a universal +5V
power adaptor, which accepts AC voltages from 100 to 240
Volts with 50 or 60 Hz line frequency.
