DVI-TP-TX200DL/RX100DL
User’s Manual Rev. 1.0
Page 7 / 29
2.3. Receiver features (DVI-TP-RX100DL)
Input Equalization – Both CATx inputs are compensated for up to 40 dB high
frequency cable loss. Automatic and user adjustable modes are
available to allow for precise setting of equalization.
TMDS reclocking – (removes jitter caused by long cables) the DVI OUTPUT has a
clean, jitter free signal, eliminating signal instability and
distortion caused by long cable or connector reflections.
Signal Present and Monitor Connected LEDs – Two LEDs indicate when a valid
DVI signal is detected and when a display device is connected
and it is sending a Hot Plug signal.
Supports highest resolutions – 2048x1536p 60 Hz, 2560x1600p 60 Hz, and
3840x2400p 30 Hz are supported including all standard HDTV
resolutions (720p, 1080i, 1080p). Unencrypted signals up to
330 MHz pixel clock frequency (up to 165 MHz TMDS clock
frequency) regardless of the resolution are passed through.
Front panel control – EQ mode selection button and 25-turn potenciometer are
available for precise equalization setting. Red and green LEDs
on the front panel indicate the actually selected EQ mode.
Fiber cable support – Self powered DVI fiber cables using +5V from DVI sources
(VGA cards, etc.) usually consume more than 55 mA, which
load is the maximum allowed by DVI 1.0 standard. DVI-TP-
RX100DL supports +5V 500 mA constant current output on DVI
OUTPUT to power long distance fiber optical transmitters.
Universal power adaptor – DVI-TP-RX100DL is equipped with a universal +5V
power adaptor, which accepts AC voltages from 100 to 240
Volts with 50 or 60 Hz line frequency.
