Related alarming,
temperature output de-energized,
ventilation de-energized,
humidity control output de-energized,
lamp on for U34 (when U30 = 0)
Auto Restart Function
After power supply stops, and comes back, the controller will run under the same settings and status.
Incubation Day Counter
When controlling, the incubation day counter will keep counting.
If the counter value reaches U18, controller keeps controlling as normal, and the counter value will be flashing.
If the counter value reaches 99, stop counting. Keeping depressed for 3 seconds will reset the accumulated times
of egg turning and incubation day counter.
Restore to Factory Default Settings
When the controller is online, keep and depressed simultaneously for 3 seconds. The display shows “UnL”.
Then press twice, the controller will restore the parameters to factory default settings.
Fahrenheit/Celsius display
Keep and depressed simultaneously for 3 seconds to switch between Fahrenheit / Celsius display.
Manually Checking the Outputs One by One
Keep depressed for 3 seconds, LCD displays “CCC”. Then press twice to enter into manual checking mode.
Now all outputs are de-energized. Press and to energize R1/R2/R3/R4/R5/R6/R7/SSR in turn.
Attention
1. Please read this instruction carefully. Electrical wiring must be manipulated by certified electrician. Wrong wiring may
damage the device and system seriously.
2. Avoid humid environment, or with corrosive gases, or strong electric-magnetic field. The device is possible abnormal in
such condition.
3. This product has been strictly tested before shipping. The company warranty is one year, the responsibility is limited to
the sale of the product itself. Damage caused by improper usage is not covered by the warranty.
Wiring Diagram
