JUMBO
TM
| 41
CBJ2 Current cut-off
CBJ2 CH1 Leg spreader CH2
Min. Max. Min. Max.
CBJ2002N 7 9 2 2.9
CBJ2003H 4.9 5.9 - -
CBJ2004H 4.9 5.9 4.7 6.2
CBJ2005N 7 9 4.7 6.2
CBJ2006H 9.8 11.8 - -
CBJ2007H 9.8 11.8 2 2.9
CBJ2008H 9.8 11.8 4.7 6.2
The minimum and maximum values stated above refer to the tolerance range, not the adjustment range.
The current cut-off tolerance is +/- 0.2 A depending on the ambient temperature (20 C)
Warnings
To avoid injury, all control boxes with variable current cut-off are preset to < 4 A, unless otherwise specified.
Recommendations
The mains cable must always be ordered separately when ordering a CBJ2 with an internal charger.
Use only original LINAK mains cables to ensure proper connection to internal charger.
The CBJ2 will not be able to operate any actuators when charging or connected to mains.
By use of charger CH01 it is possible to activate the actuators when charging. However, this is not
recommended as it can damage the control box or the charger CH01.
When the CBJ2 with LCD display option is combined with the battery BAJL, the LCD display can indicate
empty battery, even if the battery capacity is not low. The acoustic alarm will always be activated at low
battery capacity independent of display indication.
Warnings
In order to avoid injury, the emergency-stop should be activated in transport and cleaning situations.
BAJL batteries differ from BAJ lead acid as they have built-in discharge protection. If the user continues to
use the battery despite warning signals, loss of power might happen due to the battery deep discharge
protection. In this event, there may be no warning and the application may not be able to move when
expected.
The combination of CBJ2 with BAJL might not be able to complete a full cycle after low battery warning.
