CBJ Care
The control box CBJ Care is part of the JUMBO system. JUMBO is a modular
system combining an actuator, control box (CBJ Care), battery (BAJ, BAJL),
wall charger (CHJ2), control box prepared for external charger by use of
wall-plug charger CH01, and a hand control in a flexible solution, specially
developed for patient lifts.
The complete system contains a series of features which meet the patient’s need for a safe and comfortable
lift.
CBJ Care is available in 3 versions, one with LEDs, one with a display and a third without display and LEDs.
It is possible to have control buttons on the front cover to have an easy control option
if the hand control is missing. Furthermore it is possible to have 3 channels via a T-cable in channel 1. The
3rd channel for tilt function adds value for the patient and the caregiver.
Usage
CBJ Care with internal
charger:
Nominal current draw max. 400 mA
Power consumption (standby) max. 2.5 W
Power consumption (charging) max. 19 W
Duty cycle: Max. 10% or 2 min. continuous use then 18 min. without use
Ambient temperature: +5° to +40°
Storage temperature: -10° C to +50° C
Relative humidity: 20% to 80% – non-condensing
Atmospheric pressure: 700 to 1060 hPa
Meters above sea level: Max. 3000 meters
Approvals: IEC60601-1, IEC60601-1-6
ANSI / AAMI ES60601-1,
CAN/CSA-22.2 No 60601-1
Instructions for use
• Before start-up we recommend to reset the service counters – days and cycles until next service visit.
To reset press the up and down button on the control box or the hand control for 5 seconds. An audio
signal will confirm the resetting.
• When charging, the CBJ Care will not be able to operate any actuators.
• It is not possible to use other battery types than BAJ or BAJL with the CBJ Care.
• Use only original LINAK mains cables to ensure proper connection to internal charger.
• The green battery indicator (100% to 50% capacity remaining) will light up during charging even though
the battery is not fully charged. It is necessary to use the “CHARGE” LED to indicate whether or not the
battery is fully charged (when using internal charger). The CHARGE indicator will light up during charging
and turn off when the battery is fully charged.
• When resetting the CBJ Care or updating other settings than using learn mode, the CBJ Care must not
be disconnected from the battery and the emergency stop must not be activated within a time span of at
least 10 seconds. This is to ensure the correct storage of the new values to the memory banks of the CBJ
Care.
