CHJ2
The charger CHJ2 has been specially designed for use as a wall-charger for
the JUMBO system.
The CHJ2 charger is a Switch Mode Power Supply (SMPS) version which
makes charging of the batteries more efficient.
Mains voltage from 100 V AC – 240 V AC (50/60 Hz) is possible on same
charger.
The charger indicates whether the charger is connected to the mains
(green LED) or whether the battery is being charged (yellow LED). Medically
approved.
Usage
Nominal current draw: Max. 600 mA
Power consumption (standby): Max. 2.5 W
Power consumption (charging): Max. 19 W
Ambient temperature +5 °C to +40 °C
Storage temperature: -10 °C to +50 °C
Relative humidity: 20% to 80% - non-condensing
Atmospheric pressure: 700 to 1060 hPa
Height above sea level: Max. 3000 meters
Approvals: IEC60601-1
ANSI/AAMI ES60601
CAN / CSA-22.2 No 60601-1
