JUMBO
TM
| 43
Mounting
UP
DOWN
Warnings
Special care should be taken when mounting the CBJ2
As long as the the CBJ2 is mounted correctly, it complies with IPX5.
If the CBJ2 is mounted incorrectly, then water will gather around the screw holes resulting in non-
compliance with IPX5!
CBJ2 with variable current cut-off: the protection plugs must always be inserted to ensure IP protection after
adjustment.
When using the control box with emergency stop, the stop button must be activated in cleaning situations
in order to comply with IPX5. The battery pack BAJ must not be removed in cleaning situations, doing so
could result in non-compliance with IPX5.
If the CBJ2 is fitted with option B, D and F (DC power connector), the protection plug ex. 00918174 must
always be inserted to ensure IP protection, if the port is not used. IP rating only applies when the battery is
connected to the control box.
