JUMBO
TM
| 52
Recommendations
If emergency stop is pressed whilst charging, the batteries will not be charged.
When charging, the CBJ Home will not be able to operate any actuators.
For recharging the batteries, use charger CH01 (charger has to be ordered separately).
Note: Always mount the CBJ Home with the channel sockets facing downwards.
The CBJ Home is not intended for use with “buffer” type actuators such as LA28.
The actuator must always be fitted with an exchangeable cable (mini-fit) socket.
Actuators on channel 1 must always be with spline.
The mains cables must always be ordered separately when ordering a CBJ with an internal charger.
Use only original LINAK mains cables to ensure proper connection to internal charger.
Always use fully charged batteries for learning mode procedures.
Only an authorised LINAK service centre should change a battery in a CBJ Home. If a CBJ Home is opened
and a battery is changed by unauthorised personnel, there may be a risk of malfunction.
When using the control box with emergency stop button, the stop button must be released before
charging batteries or before the application is put into operation.
It cannot be guaranteed that the actuator will stop exactly at the weight that is stored as the motors in
the actuators will use less current when run in. Though it will never reach the 1.5 times max. load as the
norm states.
Tolerance for current cut off is: +/-10 %
The maximum cut-off value that can be registered (stored) is 8 Amp.
If an actuator or CBJ Home is exchanged it will be necessary to reset the max. load to ensure the correct
cut-off value for the new system as a whole.
The registration function can only be activated by using a specially produced hand control (HB7X161-00).
A standard hand control cannot activate the function.
To operate the “Learn mode” function in External charger versions produced before February 2010 press
the “R” button when “learning” (the lifting arm actuator will operate automatically). With all other
versions (and future versions with external charger) both the “R” button and the “lifting arm” button
need to be pressed.
It is possible to use the “learn mode” function for channel 2: To operate the learn mode function for
channel 2, press the “R” button and the “leg spread out” button at the same time. Run actuator with
load and full cycle to record maximum current during a cycle.
Warnings
In order to avoid injury, the emergency stop should be activated in transport situations.
When “learn mode” is used, and channel 2 is pressed instead of channel 1, the CBJ Home will learn a
new current limit of nearly 0 Amp. This will make it impossible to run the actuator with channel 2 until a
new learn mode has been programmed.
