OPERATOR’S MANUAL
For use with machines having Code Number 10378, 10379, 10539, 10540 and 10550
RANGER
TM
9
Multi-Process Gasoline Engine Driven Welder and Power Generator
IM511-D
OCTOBER, 2000
Safety Depends on You
Lincoln arc welding and cutting
equipment is designed and built
with safety in mind. However, your
overall safety can be increased by
proper installation ... and thought-
ful operation on your part. DO
NOT INSTALL, OPERATE OR
REPAIR THIS EQUIPMENT
WITHOUT READING THIS
MANUAL AND THE SAFETY
PRECAUTIONS CONTAINED
THROUGHOUT. And, most
importantly, think before you act
and be careful.
R
• Sales and Service through Subsidiaries and Distributors Worldwide •
Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com
• World's Leader in Welding and Cutting Products •
Date of Purchase:
Serial Number:
Code Number:
Model:
Where Purchased:
Copyright © 2000 Lincoln Global Inc.

Table of Contents

Questions and Answers

  • M
    Mary MatthewsAug 10, 2025
    How to fix Lincoln Electric RANGER IM511-D if engine won't crank?
    • R
      Robert SchneiderAug 10, 2025
      If your Lincoln Electric Welding System's engine won't crank or is hard to crank, here are a few things to check: * **Faulty battery:** Replace the battery with a known good one. * **Charging current:** Check the connection of the lead from the voltage regulator on the engine to the charging ammeter and battery leads #208 and #209. * **Loose connections:** Check and tighten connections at the battery, starter, engine foot, or frame. * **Broken lead:** Repair lead #216A from the solenoid to the start switch. * **Fouled spark plugs:** Replace the spark plugs.
  • B
    Brian BellAug 26, 2025
    What to do if Lincoln Electric RANGER IM511-D engine will not start?
    • D
      Debra GonzalesAug 26, 2025
      If your Lincoln Electric Welding System engine won't start or shuts down, consider the following: * **Low oil pressure:** Check the oil level and add oil as needed. * **Out of fuel:** Add fuel to the tank. * **Fuel system fault:** Repair the fuel system. * **Broken lead:** Repair the #216 lead from the start switch to the P.C. board (Onan engine). * **Faulty oil pressure switch:** Replace the oil pressure switch. * **Faulty generator terminal block connection:** Repair the connection and check leads #208, 224A, 224B, and 212. * **Faulty P.C. Board:** Replace the P.C. Board (Onan engine).
