Protected componentsFuse amp ratingFuse or relay number

RH HID headlamp.20A*15

Electronic fan.50A*16

LH HID headlamp.20A*17

Trailer brake.30A*18

Power point (console).20A*19

Not used.—20

Trailer tow module.30A*21

Passenger power seat.30A*22

Air conditioner clutch relay.Relay23

Trailer tow park lamp relay.Relay24

Not used.—25

ALT sensor.10A**26

4x4 all wheel drive module.20A**27

Trailer tow park lamp relay.25A**28

Integrated wheel end solenoid.10A**29

Air conditioner clutch relay.10A**30

252

Navigator (TB5) Canada/United States of America, enUSA, First Printing

Fuses
