Lincoln 2016 Navigator Series - Passenger Compartment Fuse Panel

Protected componentsFuse amp ratingFuse or relay number
Vehicle power 3 – powertrain control module.15A**79
Not used.—80
Not used.—81
Rain sensor.5A**82
Not used.—83
Not used.—84
Wiper motor relay.Relay85
*Cartridge fuses.
**Mini fuses.
Passenger Compartment Fuse Panel
The fuse panel is located under the
right-hand side of the instrument panel.
256
Navigator (TB5) Canada/United States of America, enUSA, First Printing
Fuses
