Protected componentsFuse amp ratingFuse or relay number
Driver window.30A1
Rear seat control.15A2
Multimedia gateway module.
Passenger window.30A3
Demand lamps.10A4
Amplifier.20A5
Rear electronic automatic temperature control.5A6
Power mirror.7.5A7
Driver seat memory switch.
Not used.—8
SYNC.10A9
Power lift gate.
Electric finish panel.
Display.
Run accessory relay.10A10
Passive entry/start module.10A11
Interior lighting.15A12
Puddle lamps.
259
Navigator (TB5) Canada/United States of America, enUSA, First Printing
Fuses
