Safety instructions
To ensure safe and efficient operation, it is
essential to read each of these warnings
and precautions and to carefully follow all
instructions listed in this manual.
• Improper use or installation of the product
can cause serious bodily injury or death.
• Do not smoke near meter or use meter
near an open flame when measuring
flammable fluids. Fire could result.
• Do not exceed 1,000 psi (68,9 bar) line
pressure.
• A filter should be used on the meter outlet
to insure no foreign material is transferred
to the fuel tank.
• To minimize static electricity build up,
use only static wire conductive hose when
metering flammable fluids, and keep the
fill nozzle in contact with the container
being filled during the filling process.
• Do not install additional foot valve or
check valve during installation without
pressure relief valve. Cracking may result.
• This product should not be used for fluid
transfer into aircraft.
• This product is not suited for use with
fluids for human consumption.
General description
The Lincoln series 900 Meter is a rotating
disc flow meter. The meter uses wheel
counters for registering either U.S. gallons
or litres.
Meter models
• Model 962 : measures flow in U.S.
gallons.
• Model 963 : measures flow in liters.
Both units are used for measuring oil lubri-
cants such as standard engine oils and
transmission fluids.
Fluid Compatibility
The 962 and 963 are compatible with the
following fluids:
• Automatic transmission fluids.
• Engine oils up to SAE 30.
If in doubt about compatibility of a specific
fluid, contact supplier of fluid to check for any
adverse reactions to the wetted materials
shown on the parts list.
!
Notice
Purge new metering systems
must prior to installation of metering
control valve to remove contaminants
from system.
Safety
The safety of Lincoln series 900 meters is
proven by their listing with:
• Underwriters Laboratories Inc. a nation-
ally recognized independent organization
for testing of Products to ensure public
safety.
• Canadian Standards Association,
a Canadian organization for testing of
products to ensure public safety.
Table 1
Specifications
Description Specification
Flow range 4–40 gal./min. (15–115 l/min.)
Maximum working pressure 1,000 psi (68,9 bar)
Inlet/outlet 1 in. (25,4mm) /1 in. (25,4mm)
3
