Page Number - 5
Form 403295
Part Qty. Description Part Qty. Description
815 1 Air coupler *35135 1 Gland packing
11470 1 Valve cap **38162 1 Valve seat gasket
11471 1 Collar, Trip Rod 40666 1 Adapter casting
11472 1 Trip rod pin 45605 1 Valve guide plate
11475 1 Trip shoe assembly 48212 2 Air piston washer
11659 1 Air nipple 48237 1 Washer
11904 1 Packing nut 48448 1 Washer
11905 1 Packing cap 48511 1 Washer
11947 1 Sleeve, Trip 51009 4 Nut
12834 1 Spring retainer **55138 4 Spring
13300 1 Piston bolt 55231 1 Spring
14090 1 Gland packing nut 56038 2 Spring
14959 1 Gland packing spacer 61041 1 Air cylinder
14960 4 Tie rod 61502 1 Air passage tube
14961 1 Piston rod 61570 1 Tube
14962 1 Coupling adapter *69102 2 Ball
14963 1 Body cap 91331S 1 Toggle plate
*30003 1 Packing nut gasket 91964 1 Trip rod
*30011 1 Valve gasket 236286 1 Cover
*31050 1 Gland gasket 236612 1 Air valve casting
*33014 2 Gasket 236615 1 Muffler cover
33039 1 Gasket *236616 1 Gasket
34090 1 Air piston packing 236833 1 Muffler packing
*34110 1 Packing 236835 1 Packing
*34158 1 0-ring 236868 4 Screw
*34310 1 Packing 236869 6 Screw
*34368 2 O-ring 236868 4 Valve seat bolt
* Included in 236464 Repair Kit. 245425 1 Trip rod packing nut
** Included in 83063 Valve Seat Assembly.
SERVICE PARTS
Problem Solution
1. Pump does not operate. Check air supply to air motor.
Replace 11475© Trip Shoe Assembly,
11947 Trip Sleeve and 91331 Toggle Plate
.
2. Air seepage from air exhaust port Replace 11482 Valve Slide©, 14919 Valve
while pump is not operating. Seat© & 38162 Valve Gasket©, 236835 Trip
Rod Packing and 236616 Gasket.
3. Excessive amount of air entrapped in Replace 34310 Packing, 35135 Gland
fluid or excessive amount of fluid coming Packing and 31050 Gland Gasket.
from air exhaust.
Note:
Some fluid exhausts with air
normally.
TROUBLESHOOTING
ACCESSORIES
Filter/regulator & Gauge/Lubricator
Eyebolt Kit
1709 Hoist
83321 Low Pressure Kit
84148 Wall mount Bracket Kit
© Indicates change
©
©
©
©
©
©
©
©
©
©
©
©
