10/23/07
Technical Bulletin 026
Product: POD XT, X3, Tone Port products
containing secure memory devices.
Overview:
The identified units below have a secure memory device installed on their respective main
PCBA’s. This device allows for a collection and transmission of an electronic serial number which
will enable the customer (end-user) to access, obtain, and purchase specific upgrades,
downloads or their user account on-line.
Service Objective:
When replacing the main PCBA in any of the following product, it is necessary to remove P/N:
15-79-0088 from the “old” PCBA and transplant it to the new PCBA.
Parts Affected:
15-79-0088- IC Memory Secure AT88SC153-00 –2.7 8S1 (SO-8) SM
Affected Product/ PCBA Locations:
POD XT and Bass POD XT: U17
POD XT Live and Bass POD XT Live: U24
POD XT Pro and Bass POD XT Pro: U8
Floor POD Plus: U24
POD X3: U4
POD X3 Live: U2
Tone Port KB37: U6
Tone Port UX8: U3
Tools/ Supplies Required:
Various hand-tools for product disassembly, soldering iron, RoHS compliant solder/ flux.
Procedure:
Remove secure memory IC, P/N: 15-79-0088 from original PCBA and transplant it to the correct
reference designator location on new PCBA.
Warranty Implications:
This is a required step in replacing the main board on any of the above-identified products and
should be considered as warranty.
Date Codes Affected:
All.
Line 6, Inc. Customer Service and Repair
3850-A Royal Ave. Simi Valley, CA 93063 P. 818-575-3600 F. 818-575-3961 E.
service@line6.com

Line 6 POD X3 Specifications

General

Type	Multi-Effects Processor
Amp Models	78
Effects Models	98
Display	LCD
Technology	Digital
Inputs	1 x 1/4" Guitar, 1 x XLR Mic, 1 x 1/4" Aux
Outputs	1 x XLR
MIDI	In/Out
USB	Yes
Power Supply	9V AC adapter (included)
