2 x Micro USB to USB Type-A Cables (L=1m)
1 x IR Emitter
1 x IR Receiver
2 x 3.5mm 3-Pin Phoenix Connector
8 x Mounting Brackets (with Screws)
Specifications
Technical
Input/Output Port
Transmitter:
1 x HDMI OUT, 1 x UTP OUT, 1 x S/PDIF IN, 1 x IR IN,
1 x IR OUT, 1 x RS232, 1 x Micro USB (for power input)
Receiver:
1 x HDMI IN, 1 x UTP IN, 1 x S/PDIF OUT, 1 x IR IN,
1 x IR OUT, 1 x RS232, 1 x Micro USB (for power input)
Audio Format Supported
S/PDIF: Dolby Digital, Dolby Digital Plus, DTS, DTS HD,
PCM 2.0
ARC: Dolby Digital, Dolby Digital Plus, DTS, DTS HD,
PCM 2.0
eARC: PCM 2.0, PCM 5.1, PCM 7.1, Dolby Digital, Dolby
Digital Plus, Dolby TrueHD, Dolby Atmos, DTS, DTS HD,
DTS HD Master Audio, DTS:X
General
Operating Temperature 0°C to 45°C (32°F to 113°F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
Humidity 10% to 90%, non-condensing
ESD Protection
Human-body Model:
±8kV (Air-gap discharge)/
±4kV (Contact discharge)
Power Supply DC 5V 1A
Power Consumption 3.582W (Max)
Device Dimension
(W x H x D)
120mm x 25mm x 70.2mm/
4.72" x 0.98’’ x 2.76’’ each for TX/RX
Product Weight 0.32kg/0.71lb
