13
1. Connect an HDMI source (such as Blu-ray player, games console, STB, Apple
TV etc.) to the HDMI IN port of the Transmitter via an HDMI cable.
2. Connect the Transmitter to the Receiver via a Cat X cable on the HDBT ports.
3. Connect an HDMI display to the HDMI OUT port of the Receiver.
4. Connect the IR emitter and IR receiver to the Transmitter and the Receiver
respectively. Users can control the source at the display location or control the
display at the source location as required, please refer to the diagrams in IR
Pass Through Section.
5. Connect the power supply to either the Transmitter or Receiver to power both
units.
Check Power, Status, and HDCP & Link lights are illuminated on both units to indicate
successful connection, with a lit HDCP light
illustrating the presence of encryption
within the signal. Power and Link are static lights. Status should be blinking.
Installation Instructions
