6
General
Operating Temperature
0°C to 45°C (32°F to 113°F),
10% to 90%, non-condensing
Storage Temperature
-20°C to 70°C (-4°F to 158°F)
10% to 90%, non-condensing
Humidity 10% to 90%, non-condensing
Power Supply DC 18V 1A
Power Consumption (Max) 4.8W
Device Dimension
(W x H x D)
5.39'' x 0.61'' x 2.93''
(136.8 mm ×15.4 mm × 74.5 mm)
Product Weight 0.53lb (0.24kg)
Certication CE, FCC
Cable Specification:
Note: LINK recommends the use of T568B straight-through Category cables.
Cable Type Range Supported Video
HDMI
49ft (15m) 1080P@60Hz
33ft (10m) 4K@30Hz
10ft (3m) 4K@60 Hz 4:4:4 8 bit with HDR
CAT5e/6
197ft (60 m) 1080P@60Hz 36 bpp
115ft (35 m)
1080P@60Hz 48 bpp
1080P@60Hz 3D
4K@60 Hz 4:4:4 8bit with HDR
CAT6a/7
230ft (70 m) 1080P@60Hz 36 bpp
131ft (40 m)
1080P@60Hz 48 bpp
1080P@60Hz 3D
4K@60Hz 4:4:4 8bit with HDR
