Linkam Scientific Instruments CSS450 User Manual

11
Getting Started
When fully unpacked, check for the following
items; CSS450 ‘Controller’, a mains power lead,
RS232 lead and a CD with Linksys32 software.
In a separate dedicated plastic case there will be a
complete CSS450 Shearing ‘Stage’ consisting of
the Lid, the Base, a flat packed Stand and an
accessories kit.
Installing Linksys32 on a PC
Before getting started with the stage, it is advisa-
ble to load the Linksys32 software onto the PC
(see Linksys32 Manual) and register the software
with Linkam.
Note: The CSS450 Controller requires a PC
equipped with a Comm port (RS232 connection),
for the Controller to link with the PC. If the PC
does not have a Comm port, consult your IT
department to install a Comm port PCI card or a
USB-to-Comm port adaptor.
Stand Assembly
Assemble the Stand as shown in the pictures,
using the supplied 4.0mm hex key.
The Stand is useful for holding the Lid while a
sample is loaded or when the windows are
cleaned.
It can also be used to rest the complete shearing
stage on when testing or when it is not in use on
the microscope.
CSS450 System

Linkam Scientific Instruments CSS450 Specifications

General

Cooling Method	Liquid Nitrogen Cooling
Temperature Accuracy	±0.1 °C
Temperature Stability	±0.1 °C
Sample Viewing	Optical access via windows
Temperature Range	-196°C to 450°C
Temperature Control	PID control
Heating Method	Electrical
Sample Holder	Standard sample holder or custom options
Communication Interface	RS232
Chamber Size	Variable, depending on sample holder
Atmosphere Control	Inert gas
